Samsung 32" Smart signage QM32C

Display

• Diagonal Size32"
• Panel TypeVA
• Resolution1,920 x 1,080
• Pixel Pitch (HxV, mm)0.36375 x 0.36375 (mm)
• Brightness (Typ)400 nit
• Contrast Ratio4,000:1
• Viewing Angle (H/V)178/178
• Response Time8ms
• Color Gamut72% (NTSC)
• Glass Haze2%
• H-Scanning Frequency30 ~ 81kHZ
• Maximum Pixel Frequency148.5MHz
• V-Scanning Frequency48 ~ 75HZ
• Contrast Ratio (Dynamic)Mega
• Operation Time Support16/7

Connectivity

• HDMI In3
• DP InNo
• Version of HDMI1.4
• Version of HDCP2.2
• USB2
• IR InYes
• Audio InNo
• Audio OutStereo Mini Jack
• RS232 InYes
• RS232 OutYes
• RJ45 InYes
• WiFiYes
• BluetoothYes

Power

• Power SupplyAC100-240V 50/60Hz
• Power Consumption (Off Mode, W)-
• Power Consumption (On Mode, W)55 W
• Power Consumption (Sleep Mode, W)0.5 W

Dimension

• Set Dimension (WxHxD, mm)727.3 x 421.9 x 28.5 mm
• Package Dimension (WxHxD, mm)817 x 507 x 119 mm

Weight

• Set Weight (kg)5.2 kg
• Package Weight6.9 kg

Operation Conditions

• Temperature0?~ 40?
• Humidity10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount (mm)100 x 100 mm
• Bezel Width (mm)11.5(U/D/L/R)
• Frame MaterialNon-Glossy

Optional Feature

• StandSTN-L3200C

SoC

• OS VersionTizen 7.0
• Flash Memory Size8GB

Eco

• Energy Efficiency ClassA+

Certification and Compliance

• EMCClass B
• Safety60950-1, 62368-1
