CP-EST-6TGD23-305 Cat6 24AWG UTP Outdoor LAN Cable (Double Jacket) (214mtr)
₹8,560.00
(Inclusive of all taxes)
(Inclusive of all taxes)
| Conductor | Solid Bare Electrolytic Grade Copper |
| Nominal Conductor Diameter | 23 AWG |
| Insulation | Polyethylene (LDPE) |
| No. of Pair | 4, Each pair Twisted |
| Pairing | Twisted into Two core |
| Outer Sheath | PVC Sheath/ LSZH |
| Colour of Sheath | Grey (RAL-7035), Option Available |
| Approximate OD | 5.480mm |
| Rip Cord | Yes |
| Cross Filler | HDPE |
| Sequential Marking | Every Meter |
| Resistance Unbalance | 5% Max |
| Conductor Resistance of solid cable | 93.5?/1000 Mtr@20°C Max |
| Mutual Capacitance | 5.6nf/100Mtr. Max |
| Packing | 305 Mtrs |
| Temperature Rating | -20 to +60°C |
| Storage Temperature | -20 to +75°C |
| NVP | 69% |
| Impedance | 100±15% ? |
| Tensile | 110N |
